Quick Description:
- 2 MP full time color turret camera
- 24/7 full color imaging
- 2.8 mm fixed focal lens
- Warm supplemental light with 20 m range
- Clear imaging even against strong back lighting due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- Water and dust resistant (IP67)
- 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS).
Specifications:
Camera:
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Frame RatePAL: 1080p@25fps NTSC: 1080p@30fps
- Resolution1920 (H) × 1080 (V)
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
- Lens2.8 mm fixed lens
- Horizontal Field Of View2.8 mm, horizontal FOV: 104°, vertical FOV: 54°, diagonal FOV: 126°
- Lens MountM16
- Day & NightColor
- WDR (Wide Dynamic Range)130 dB
- Angle AdjustmentPan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
Menu:
- Image ModeSTD/HIGH-SAT
- AGCSupport
- Day/Night ModeColor
- White BalanceATW/MANUAL
- HLCYes
- BLC (Backlight Compensation)Yes
- LanguageEnglish
- FunctionsBrightness, Sharpness, 3D DNR, Mirror, Smart light
Interface:
- Video OutputSwitchable TVI/AHD/CVI/CVBS
General:
- Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
- Power Supply12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.
- Power ConsumptionMax. 3 W
- Protection LevelIP67
- MaterialMain Body: Metal Enclosure: Plastic
- CommunicationHIKVISION-C
- White Light RangeUp to 20m
- DimensionsØ 109.82 mm × 85.56 mm ( Ø 4.32″ × 3.37″)
- WeightApprox. 336 g (0.74 lb.)
